WHAT IS IT?

BYB Telemetry detects the motion of the suspension
and other dynamic parameters of the MTB while riding.

It allows to visualize the motion of the suspension,
in order to base the setting
on
quantitative information instead of feelings.

HOW BYB TELEMETRY CAN IMPROVE YOUR PERFORMANCE?

Suspension technology has drastically evolved
in the last years, reaching an incredibly h
igh standard
of quality
and performance, but also complication level.

With more tuning parameter available on every suspension system, finding a proper suspension set-up is not a straightforward operation.


Every rider would like to have a perfectly balanced
and smooth bike on a rough or technical section.
In fact, an optimal set-up can make the difference concerning chronometric feedback and fatigue.
This is true for the
professional, but also for the amateurs riders.



These are the benefits you will get when using data instead of feelings.

HOW BYB TELEMETRY WORKS?

Thanks to a set of universal supports,
BYB Telemetry can be easily installed
on every bike: downhill, enduro, cross country and e-bike
in only 15 minutes.

It's designed to be minimal on the bike and professional-grade.



You can start riding immediately
because
no calibration is needed.



After your sessions, you can directly download
your runs to our software & app
in order to
analyze the data
and get the best out of your bike!

MAIN FEATURES

SAY HELLO TO BYB TELEMETRY v2.0!

WHAT'S NEW?

From now BYB v2.0 is professional and easier than ever!

We improved the accuracy, increase the sampling rate to 1000Hz, added new LEDs and new sensors in less of the same overall footprint!

SYSTEM MAIN FEATURES

  • Easy-to-use interface

  • Two different sampling mode

  • Sampling Rate (500 Hz and 1000 Hz)

  • Motorsport-grade fork and shock sensors

  • Bike-specific brakes and speed sensors

  • Built-in 3-axis accelerometer, gyroscope, and GPS

  • Shock at the handlebar detection

  • Extra-channel for custom applications

  • Universal mountings

  • Waterproof

  • Long-lasting internal battery

SOFTWARE MAIN FEATURES

  • Wireless download to software and app

  • Runs history and library consultable any time

  • Deep analysys of suspension position and speed

  • Usefull and statistical metrics

  • Real rear-wheel leverage interpolation

  • Overall suspension and overall bike balance

  • High-intuitive charts to immediate understanding

  • Deep comparison between runs,
    including time gain/loss

  • Life-time free updates

SPECIFICATIONS

ELECTRONIC AQUISITION UNIT

 Two different sampling mode

High sampling rate (500 or 1000 Hz)

On-board wireless connection technology

Built-in automotive-grade GPS

IP67 connectors

10 total channels

More than 10h of continuos sampling

Mountable on every handlebar 31,8/35mm

4 GB of available on-board space

Built-in inertial sensors

 Made in Italy

Waterproof anodized alumiunm case

HIGH SAMPLING RATE

Guarantee a fast sampling rate is crucial for these task. That's why we designed this version as a real power-house.

The literature about road bike competition, which are characterized by lower shaft speeds, claimes that the minimum acceptable sampling rate is around 400Hz.

In high-impacts sports, such as mountain-bike, it's necessary to push this value more.

BYB offers 1000 Hz sampling rate for the best accuracy. It's possible to set the system to acquire also at 500Hz.

AUTOMATIC CALIBRATION

CALIBRATION

The calibration is totally automatic. It's required only a moment with both suspension fully extended during the run, for example a jump.

ADAPTABLE TO EVERY TRAVEL

The sensors that come inside the kit can be used with all fork below 200mm and shock absorbers below 75mm.

No additional calibration are required.

BUILT-IN SENSORS

Automotive-grade GPS

3-axis accelerometer

3-axis gyroscope

BYB detects the shock and the vibrations at the handlebar plus the spatial orientation of the bike.

The GPS is equipped with an external antenna in order to get a strong signal also inside the woods. Precise comparison needs an equally accurate GPS.

SUSPENSION SENSORS

Standard fork lenght 200mm

Standard shock lenght 75mm

High accuracy technology

Motorsport grade sensors

Compact body

Auto-alignament universal joints

IP65 sealing (with low actuation force)

OTHER SENSORS

Digital brakes sensors

Analog brakes sensors (optional)

Fast to install brakes sensor

Don't require to open the hydraulic circuit

Rear-wheel speed sensor (optional)

Front-wheel speed sensor

MOUNTINGS & HARDWARE

Fast and easy to use

Installable on air spring suspension

Specifically designed support for MTB

The mountings that come alongside the kit are usable almost on every bike.



As every bike is different, if something doesn't fit, we will be happy to help you in order to make some custom-made support.

UNIVERSAL BETWEEN ALL THE DISCIPLINES (+MX)

Install BYB on your downhill, enduro,

cross-country or e-bike.

From today,

it's possible to get the data straight from you MX too!

It's the same acquisition unit with a different bundle of sensors.



Visit the Motocross page to learn more

READY FOR THE FUTURE AND TO BE EXPANDIBLE

Firmware upgrade

Fully compatible with future generation sensors

New upgrades availables at any time

Can handle ten channels max

Ready to be engineered for custom applications

For special needs or custom applications get in touch with us.

APP & SOFTWARE FEATURES

Get the best out of your bike by observing the charts inside the software.

Store your settings or add notes, and if you can't use your PC, feel free to use the official mobile application.

Almost every month is released a new version and all new updates and features are back-word compatibility and free, lifetime.

Visit the Software and App page to learn more

WHAT'S IN THE BOX?

  • Acquisition unit

  • Fork sensor (200 mm)

  • Shock sensor (75 mm)

  • Front brake digital sensor

  • Rear brake digital sensor

  • Front wheel speed sensors

  • GPS antenna

  • Handlebar mountings

  • Complete set of universal mountings and screws

  • Charging cable

  • Smartphone application

  • Software with lifetime updates

USER MANUALS

DATASHEETS

COMING SOON

Acquisition unit

Front sensor

Rear sensor

Brake sensor

Speed sensor
